| Technical Data |
|
| Measuring value |
Precipitation (yes / no) |
| |
Precipitation "no" = Relay is switched on |
| |
Precipitation "yes" = Relay is switched off |
| |
Sensor "off" = Relay is switched off |
| Signal output |
Semiconductor relay, Potential-free, electrically isolated,
metallically separated |
| Relay- contact voltage |
max. 26 VAC / 36 VDC, max. 0,5 A (cos f > 0.9),
0,2 A (cos f = 0.4) |
| Switch-on delay |
< 0.5 s Signal- Output, 15 s Heating |
| Operating voltage |
11...28 VAC oder 11...32 VDC (max. 0,75A) Verpolungsschutz |
| Current consumption |
Heating off: < 15 mA |
Heating on:
max. 0.35 A (@ 11...12 VAC operating voltage)
max. 0.75 A (@ 12...27 VAC operating voltage)
max. 0.3 A (@ 27...32 VAC operating voltage) |
| Sensor area |
18 cm² |
| Sensitivity |
Approx. 0,2 mm/h |
| Ambient temperature |
-30...+60°C |
| Protection |
IP 66 acc. to DIN 40050 |
| Weight |
Approx. 150 g |
| Material |
Housing: Polycarbonate (PC), UV-stabilised, white (RAL 9010)
Sensor: Ceramic (aluminum oxide AL2O3), glass-coated
Fixing kit: Stainless steel 1.4301 for pole mounting. |
| Connection |
5.4106.00.000
Cable, non-detachable, type: LiYY 4 x 0.25mm², 3m long |
5.4106.00.100
Cable, non-detachable, type: LiYY 5 x 0.14mm², 3m long |
