For digital pyrometer of series
5; 10; 50; 120; 500
- Automatic detection of the pyrometer type
- For parametrizing of pyrometers
- Actual temperature reading
- Simple menu operation
- Interface selectable RS232 <="=>" RS485
- UPP® (Universal Pyrometer Protocol)
Display
LCD, 2 x 12 characters
Interface (selectable)
RS232 or RS485 half duplex
Connector
9-pin sub D connector (female)
Language of display (selectable)
German, english, french, italian, spain
Display of temperature (selectable)
°C / °F
Data protocol
UPP® (for all stationary digital IMPAC pyrometers)
Battery
9 V IEC 6 F22 / IEC 6 LR 61 (500 mAh)
Battery life
~ 18 h
CE-label
Corresponding EU rules about electromagnetic immunity
Protection class
IP30
Max. ambient temperature
0 ... 50°C
Storage temperature
-10 ... +60°C
Weight (incl. batterie)
Approx. 220 g
Dimensions
189 x 72 x 37 mm
Reference number: 3 826 500
